Specifications
- Total bending line weight: 2,750 lbs
- Motor: 1 HP x 2 units
- Power: 3 phase, 220V/380V, 50/60 Hz
- Bending line dimension: (L) 94” x (W) 63” x (H) 51”
- Steel bar bending machine up to #5 bar
- Bending machine with 2 heads
- Air compressor: 2 HP x 1 unit
- Min. inner length: 3.8”
- Max. inner length: 71”
- Bending capacity: #3 bar to # 5bar
Number of rebar to bend at one time
| Diameter of rebar | (10 mm) #3 | (12 mm) #4 | (16 mm) #5 |
| Pieces of rebar | 5 | 4 | 2 |
