Stop By Our Booth At The Offshore Technology Conference
In a couple of weeks, C Marshall Fabrication Machinery will be attending the 2013 OTC in
Image Courtesy Of: OTC Facebook
- In the World’s Energy Capital: Combine OTC with client meetings, business proposals, and company training.
- Investing Back in the Industry: OTC’s sponsoring organizations use revenue to provide many other important programs for its members, such as training and technical journals.
- Always Something New: Encounter different languages being spoken, never-seen-before technologies, and C-suite speakers that you might not hear anywhere else.
PH Variable Geometry Plate Bending Machine (3 roll)
Top roll with vertical movement and side rolls moving horizontally.
Three motorized rolls through planetary gearboxes.
Permanent lubrication.
Double spherical roller bearings.
Rolls cambering based on the thickness to be rolled in order to avoid any type of roll deflection.
Easy to operate.
Especially suitable for high thicknesses.
Efficient.
Click image to left for brochure.
...
AL Variable Geometry Section Bending Machine
This bending machine is suitable for bending aluminium and steel profiles. It has variable geometry 3 driving rolls with variable interaxis.
Click picture to the left for full description....
AR Section Bending Machine
Using the same award winning technology incorporated in their world famous 3 & 4 roll plate bending machines, MG team has revolutionized the section & angle rolling market. Using the same characteristics and components as in their plate bending machines MG is able to offer stronger machines with quality and performance higher than other manufacturers and with a very competitive price. Heavy steel fabricated frames machined on CNC machining centers to ensure extreme accuracy. * Three drive rolls each with an independent hydraulic planetary motor. * Eliminating secondary reduction gearing, connecting arms, chains, synchronization devices and clutches. * Two forming rolls for reduction of flat ends. * Double roll spherical bearing (SKF or equal) for maximum rigidity. * Hydraulic motors attached directly to each planetary drive, eliminating loss of torque. * Tooling is modular and can be configured to roll most standard sections * For rolling pipe and tube or beams and channels the hard way, special tooling can be ordered.
Click image above for brochure....
MG Production
AR- line: Section bending machines with three driving rolls, each with an independent hydraulic planetary motor, two forming rolls for reduction of flat ends. Double roll spherical bearings for maximum rigidity, hydraulic motors attached directly to each planetary drive, eliminating the loss of torque. Winner technology for all section bending types up to 500 HE beams.
PK Model is simple in its design but strong and reliable, it offers mass production with the minimum maintenance. Completely re-designed in its frame and systems, gets from MH range the torsion bars, levers and transmission systems and the opportunity to adapt vacuum conveyor, loading table, supports and ejecting system. Winner technology at the right price.
MH 4-rolls: MG has updated the radial movement of their machines resulting in stronger and more efficient side rolls movements rolling even when the machine works at its capacity limit. The hydraulic motors of the two central rolls are coupled to their planetary gear boxes. The gear boxes are mounted directly on the rolls without secondary transmissions, this way there is no lost of power and no need of parts maintenance. Massive torsion bars grant the absolute rolls parallelism. These torsion bars together with all the hydraulic device generate a peculiar system that gives absolute precision and versatility. Winner technology for great performance and safety.
AK MG 3-roll: Having the same features of MH line the 3 rolls range is build with 3 powered rolls; all MG bending rolls are manufactured expressly under customer needs. Our range is the largest in the field; from 300mm to 8000mm width, for thickness from 0,2mm up to 200mm cold rolling. Winner technology at customer’s disposal.
Please click image above for the brochure....
PK 2-roll
Completely re-designed frame and systems, MG 2 roll plate bending machine model PK now offers a higher performance. The electro-welded frame is constructed using the
proven engineering principles we apply on our most famous MG 4 roll plate bending machine MH model range. The experience gained in the many years of manufacture of the MH model has now been passed onto the PK range. In particular the design of torsion bars, levers and transmission systems. Our new PK model is simple in its design but strong and reliable, it offers mass productions with the minimum of maintenance. Its mechanical, electrical and hydraulic components are purchased from world renowned companies, therefore, if required, replacement parts are easily located throughout the world.
Click HERE for the brochure....
MH 4-roll
Frames made out of welded steel and worked on CNC milling-boring machines. Power drive: • The model "MH" has both the upper and the lower roll powered with hydraulic motor and planetary gear box. • Rolls made out of forged steel. • All movements of rolls are hydraulic powered. MG owns a new geometry bending system characterized by radial movements of the bending rolls and movements totally assembled on high load dynamic
bearings that grant minimum friction and a smooth rolling even when the machine works at its capacity limit. The bearings supporting the rolls are mounted in watertight compartments with grease, protected from the external dust and pollution and having permanent lubrication. The hydraulic motors of the two central rolls are coupled to their epicycloidal gear boxes. The gear boxes are mounted directly on the rolls without secondary transmissions, this way there is no lost of power and no need of parts maintenance. Massive torsion bars grant the absolute rolls parallelism. These torsion bars, together with all the hydraulic device, generate a peculiar system that gives absolute precision and versatility.
Click image to left for the brochure....
AK-MG 3-roll
Frames made out of welded steel and worked on CNC milling-boring machines. Power drive: • The model "AK - MG" has all rolls powered with hydraulic motor and planetary gear box. • All rolls made out of forged steel. • all movements are hydraulic. MG owns a new geometry bending system characterized by radial movements of the bending rolls and movements totally assembled on high load dynamic bearings that grant minimum friction and a smooth rolling even when the machine works at its capacity limit. The bearings supporting the rolls are mounted in watertight compartments with grease, protected from the external dust and pollution and having permanent lubrication. The hydraulic motors of the rolls are coupled to their epicycloidal gear boxes. The gear boxes are mounted directly on the rolls without secondary transmissions, this way there is no lost of power and no need of parts maintenance. Massive torsion bars grant the absolute rolls parallelism. These torsion bars, together with all the hydraulic device, generate a peculiar system that gives absolute precision and versatility.
Please click image above for brochure....
