Specifications:
- Cutting Capacity- diameter of applicable hard-steel bar; grade6 #3 ~ #10 (0.375” ~ 1.26” in diameter)
- Applicable steel bar; deformed steel bar
- 3 Phase 220V 60hz
- Weight- 1355 lbs
- Dimension- 31.5″(L) 20.4″(W) 50″(H)
- Extra set of cutter blades included
No. of Bars to be Cut at a Time:
- #9 ~ #14 – 1
- #8 – 2
- #7 – 2
- #6 – 6
- #5 – 5
- #4 – 6
- #3 – 8
Features:
- Heavy duty cutting performance (bar diagram up to 32 mm).
- The electric motor is put inside the machine not to be exposed to rain.
- All the gears of the machine are in oil bathed lubrication. Therefore the machine is being operated smoothly and with less noise.
- All 4 edges of a cutting blade can be used ( bar diagram up: to 32 mm).
